LAND ROVER RANGE ROVER SPORT UK Recall Check

---

Recalls Number (Vehicles Effected)

R/2024/167 (0)

Manufacturer Reference

N865

Defect

For the affected vehicle a concern has been identified where the there is an inadequate depth of weld (penetration) between the busbar and the anode in the module of the Plug-in Hybrid Electric Vehicle (PHEV) battery.

Remedy

Replacement of the traction battery.

---

Recalls Number (Vehicles Effected)

R/2024/100 (2)

Manufacturer Reference

N853

Defect

A concern has been identified where the clamps used to secure the fuel injectors into the cylinder head on certain AJ20-D6 engines may crack allowing the injector to come loose. This loose injector could become unseated allowing fuel to be pushed past the injector seal from the combustion chamber or the fuel feed system.

Remedy

A fuel leak in this area could result in fuel spill onto hot engine components which may result in a fire.

---

Recalls Number (Vehicles Effected)

R/2023/359 ()

Manufacturer Reference

N830

Defect

On affected vehicles the right-hand tailgate and body mounted rear lamps may experience water ingress leading to one or more lamp failures.

Remedy

The right-hand tailgate and body mounted lamps will be replaced

---

Recalls Number (Vehicles Effected)

R/2023/359 (1582)

Manufacturer Reference

N830

Defect

On affected vehicles the right-hand tailgate and body mounted rear lamps may experience water ingress leading to one or more lamp failures.

Remedy

The right-hand tailgate and body mounted lamps will be replaced

---

Recalls Number (Vehicles Effected)

R/2023/360 (4)

Manufacturer Reference

N837

Defect

On affected vehicles there is concern that the structural adhesive applied to the bodyshell has been mis-applied.

Remedy

Install two rivets and seal with approved sealant.

---

Recalls Number (Vehicles Effected)

R/2023/338 (67)

Manufacturer Reference

N845

Defect

On affected Range Rover vehicles fitted with V8 Gasoline NC11 engines the fixings used to secure the engine mounted oil cooler hoses have been found to have inadequate thread engagement.

Remedy

Vehicles will have the engine oil cooler pipe fixings inspected and replaced if required.

---

Recalls Number (Vehicles Effected)

R/2023/244 (2)

Manufacturer Reference

Defect

For certain vehicles the bolt connecting the busbar to the traction battery module connector has not achieved the required clamp force. Arcing at the joint and excessive heat generation cannot be ruled out with the consequence that this may lead to a vehicle fire.?

Remedy

Replacement of the High Voltage battery

---

Recalls Number (Vehicles Effected)

R/2023/044 (499)

Manufacturer Reference

N763

Defect

For certain 2023 Model Year 3.0L AJ20-P6 Land Rover Range Rover Range Rover Sport Range Rover Velar Discovery and Defender vehicles a small number of engines the cam carrier oil gallery hasn?t been fully drilled. As a result the oil channel could be blocked leading to accumulation of oil against the pressure control valve rubber membrane and subsequently an external oil leak or increased oil carryover into the air intake system.

Remedy

The engine cam carrier will be inspected and where an incorrectly machined cam carrier is found replace it with a correctly machined component. Depending on mileage and engine conditions further associated components may require replacement.

---

Recalls Number (Vehicles Effected)

R/2023/087 (18151)

Manufacturer Reference

N785

Defect

On affected vehicles there is a risk where the water pump pully drive belt can become damaged leading to detachment or destruction. Where water pump pully drive is lost this leads to a loss coolant flow in the engine.

Remedy

Affected vehicles will have the engine coolant elbow replaced. In addition a turbocharger feed coolant pipe will be replaced.

---

Recalls Number (Vehicles Effected)

R/2023/073 (3)

Manufacturer Reference

N744

Defect

On certain vehicles the left-hand headlamp aim has been set incorrectly.

Remedy

Vehicles will have the left-hand headlamp aim adjusted to correct the issue.

---

Recalls Number (Vehicles Effected)

R/2022/222 (2981)

Manufacturer Reference

N720

Defect

Damaged front seat belt pretensioner tube may have been installed on the seat belt retractor.

Remedy

Inspect the seat belt pretensioner tube for damage and if damage is identified the seat belt retractor will be replaced.

---

Recalls Number (Vehicles Effected)

R/2021/296 (14215)

Manufacturer Reference

N573

Defect

The upper cover of the rear spoiler may delaminate and on rare occasions detach from the main body of the rear spoiler.

Remedy

Inspect the spoiler assembly and if it has not begun to delaminate a new specification adhesive will be applied. Where the outer surface of the rear spoiler has already detached and has been lost or damaged a new rear spoiler will be installed.

---

Recalls Number (Vehicles Effected)

R/2020/293 (144)

Manufacturer Reference

N496

Defect

The Exhaust Gas Recirculation (EGR) crossover pipe may have been manufactured away from specification.

Remedy

Check and repair the vehicle with a part manufactured to the correct specification.

---

Recalls Number (Vehicles Effected)

R/2019/049 (4779)

Manufacturer Reference

N291

Defect

Vehicles failed to routinely achieve the required levels of CO2 emissions.

Remedy

Update the vehicle software to the latest version.

---

Recalls Number (Vehicles Effected)

R/2019/112 (38)

Manufacturer Reference

N306

Defect

The routing of the electrical harness within the steering column assembly has insufficient clearance.

Remedy

Inspect the steering column electrical harness apply further protective material and repair damaged wiring where required.

---

Recalls Number (Vehicles Effected)

R/2019/015 (2331)

Manufacturer Reference

N277

Defect

The directional indicators may fail to operate.

Remedy

Update the vehicle with the latest software on affected vehicles.

---

Recalls Number (Vehicles Effected)

R/2019/013 (219)

Manufacturer Reference

N276

Defect

The crankshaft pulley retaining bolt may fracture due to a production specification error.

Remedy

Replace the crankshaft pulley centre retaining bolt with one that has been manufactured to the correct specification.

---

Recalls Number (Vehicles Effected)

R/2018/243 (24)

Manufacturer Reference

N227 issue 1

Defect

Autonomous Emergency Braking (AEB) feature will not be available.

Remedy

On affected vehicles download the latest software to the vehicle.

---

Recalls Number (Vehicles Effected)

R/2018/160 (1000)

Manufacturer Reference

N219

Defect

"On certain 2018 and 2019 Model Year Land Rover Range Rover and Range Rover Sport PHEV vehicles where the indicated fuel level on the fuel gauge shows approximately 30% the fuel tank is empty resulting in an engine stall.The vehicle will enter into reduced performance mode and if the customer continues to drive the vehicle will continue to run for circa 8 miles/13Km. The vehicle engine will then cut out without warning. If the traction battery charge status is at least 10% or greater the electric motor will take up drive until such time as traction battery power is depleted. Where the traction battery charge status is below 10% drive from the electric motor is not possible and the vehicle will cut out whilst in motion. All 12 volt powered electrical functions such as power assisted steering exterior lighting and brake assistance will continue to operate as designed.Engine cut out with minimal warning to the driver may lead to an increased risk of an accident."

Remedy

Fit a new revised fuel level sensor float to the vehicle.

---

Recalls Number (Vehicles Effected)

R/2018/036 (1537)

Manufacturer Reference

N138

Defect

The brazing of the fuel rail end caps is inconsistent and may not correctly seal the fuel rail ends. Fuel vapour and liquid fuel leaks can occur over time. This can lead to a liquid fuel leak into the engine bay.

Remedy

On affected vehicles replace the fuel rail with a correctly manufactured version.

---

Recalls Number (Vehicles Effected)

R/2017/288 (14932)

Manufacturer Reference

N124

Defect

Due to a software issue the Instrument cluster may intermittently go blank.

Remedy

Affected vehicles will be recalled to have the latest software installed/downloaded.

---

Recalls Number (Vehicles Effected)

R/2017/145 (836)

Manufacturer Reference

N033

Defect

The fuel return hose may leak. Increased fuel odour may be noticed and drivers may also observe liquid fuel puddles underneath the vehicle. It is possible that fuel may leak onto the road surface which can present a skid hazard to other road users increasing the risk of a crash. Should leaking fuel come into contact with a sufficiently hot surface in the engine bay there will be an increased risk of fire.

Remedy

Recall the vehicles that are likely to be affected and replace the fuel return hose.

---

Recalls Number (Vehicles Effected)

R/2017/138 (5170)

Manufacturer Reference

N029

Defect

The Emergency Locking Retractor in the front passenger safety belt assembly may not function correctly. The Emergency Locking Retractors are equipped with a vehicle-sensitive locking mechanism and a webbing-sensitive locking mechanism. The vehicle-sensitive locking mechanism may not lock as designed. In the event of a pre-crash brake event where the passenger airbag deploys front passenger seat forward facing child seat occupants may sustain more severe injuries.

Remedy

Recall the vehicles that are likely to be affected and replace the left hand front seat belt assembly.

---

Recalls Number (Vehicles Effected)

R/2017/103 (139)

Manufacturer Reference

N026

Defect

The front passenger airbag may not function properly due to a deviation in generant mix ratio. In the event of a crash of sufficient severity the front passenger airbag may not deploy when required. Failure to deploy can lead to increased injuries to the passenger seat occupant.

Remedy

Recall the vehicles that are likely to be affected and replace the front passenger airbag.

---

Recalls Number (Vehicles Effected)

R/2016/307 (452)

Manufacturer Reference

P094

Defect

It has been identified by the air-bag manufacturer that the air-bag initiator generant mix ratio does not meet specification. This can therefore result in the initiator not functioning correctly which can lead to non-deployment of the air-bag. Should a collision occur then there is an increased risk of injury to the passenger.

Remedy

Recall all affected vehicles to replace the air-bag with a new quality assured component.

---

Recalls Number (Vehicles Effected)

R/2016/303 (8628)

Manufacturer Reference

P095

Defect

It has been identified by the seat belt Pre-Tensioner manufacturer that the pre-tensioner initiator generant mix ratio does not meet specification. This can therefore result in the initiator not functioning correctly which can lead to none activation of the pre-tensioner.

Remedy

Recall all affected vehicles to check the pre-tentioner and if required replace it with a new quality assured component.

---

Recalls Number (Vehicles Effected)

R/2016/098 (11290)

Manufacturer Reference

PO80

Defect

An incorrectly manufactured crank position sensor may cause the engine to unexpectedly cut out or not to start.

Remedy

On recalled vehicles the engine serial number will be checked and if within the affected range the crank position sensor will be replaced.

---

Recalls Number (Vehicles Effected)

R/2015/187 (152)

Manufacturer Reference

P072

Defect

The second row seat backrest on vehicles with the manual recline second row seat system may not latch robustly in position. It is possible the seat belt may not correctly restrain the occupant in the event of a collision.

Remedy

On affected vehicles inspect the second row seat mechanism and if necessary fit the correct specification components.

---

Recalls Number (Vehicles Effected)

R/2015/119 (35250)

Manufacturer Reference

P068

Defect

The door could be unlatched when in the closed position and no indication provided of an unlatched condition. Vehicle doors not latched in either the primary of secondary state may during driving open. This can increase the risk of a vehicle crash and/or compromise the safety of vehicle occupants and other road users.

Remedy

Recall the vehicles that are likely to be affected and download the latest level of software. A limited number of vehicles may also require a Remote Function Actuator module to be fitted.

---

Recalls Number (Vehicles Effected)

R/2015/036 (926)

Manufacturer Reference

P056

Defect

On affected vehicles the road wheel nuts may not have been manufactured to the correct specification. These wheel nuts may crackwhen subject to shock loads and detach from the stud. This may lead to insecurity and possible detachment of a road wheel.

Remedy

Recall affected vehicles and replace wheel nuts. Locking wheel nuts are not affected.

---

Recalls Number (Vehicles Effected)

R/2015/038 (4860)

Manufacturer Reference

P058

Defect

The ground wiring for the air conditioning blower within the cockpit harness may not be to specification. This can lead to the wire getting hot and melting the plastic insulation and associated burning smell. If ignored and the loom gets significantly damaged there is a possibility of fire.

Remedy

Recall the vehicles that are likely to be affected and replace the earth wire. Where other wiring/insulation is affected necessary repairs will be carried out using the correct repair procedures.

---

Recalls Number (Vehicles Effected)

R/2015/013 (1575)

Manufacturer Reference

P052

Defect

On affected vehicles the servo vacuum hose may have been incorrectly routed and can chafe against the auxiliary drive pulley. This can lead to failure of the hose and a loss of brake servo assistance.

Remedy

On affected vehicles check brake servo hose. If in good condition correctly reroute and secure hose. If hose is damaged replace hose and correctly route and secure.

---

Recalls Number (Vehicles Effected)

R/2015/013 (1575)

Manufacturer Reference

P052

Defect

On affected vehicles the servo vacuum hose may have been incorrectly routed and can chafe against the auxiliary drive pulley. This can lead to failure of the hose and a loss of brake servo assistance.

Remedy

On affected vehicles check brake servo hose. If in good condition correctly reroute and secure hose. If hose is damaged replace hose and correctly route and secure.

---

Recalls Number (Vehicles Effected)

R/2014/091 (1331)

Manufacturer Reference

P044

Defect

An internal fault can create a short circuit within the fan control module which may lead to overheating of the insulation and ultimately fire within the engine bay. This may happen with the engine switched off and possibly when the vehicle is unattended..

Remedy

Replace electric cooling fan assembly on affected vehicles

---

Recalls Number (Vehicles Effected)

R/2013/124 (1772)

Manufacturer Reference

P035

Defect

For vehicles fitted with Dynamic Response System (DRS) it is possible that the positive battery cable could come in contact with the DRS fluid supply pipes. If this condition occurs the positive battery lead could chaff on the DRS pipe which will then lead to DRS pipes becoming positively charged. Should the charge find an earth then localised melting of components could occur due to heat generation. This could ultimately result in a vehicle fire.

Remedy

Recall all affected vehicles to check and if necessary replace the positive battery cable then reroute the cable.

---

Recalls Number (Vehicles Effected)

R/2009/073 (77262)

Manufacturer Reference

P017

Defect

It has been identified that some vehicles may experience a reduction in braking performance leading to increased stopping distance due to the possibility of oil entering the brake booster or the brake vacuum pump non-return valve sticking in the closed position after cold start.

Remedy

All recalled vehicles will be fitted with a modified brake vacuum pipe along with a revised design non-return valve in the secondary port of the vacuum pump.

---

Recalls Number (Vehicles Effected)

R/2009/051 (14330)

Manufacturer Reference

P008

Defect

Fuel may leak from the fuel pump front bearing which could lead to poor performance smell of fuel fuel leakage at the rear of the engine fuel leak onto the ground and in the worse case fire.

Remedy

Recall the vehicles that are likely to be affected to replace the high pressure fuel pump drive belt belt tensioner the high pressure fuel lines and the fuel filter.

---

Recalls Number (Vehicles Effected)

R/2009/073 (77262)

Manufacturer Reference

P017

Defect

It has been identified that some vehicles may experience a reduction in braking performance leading to increased stopping distance due to the possibility of oil entering the brake booster or the brake vacuum pump non-return valve sticking in the closed position after cold start.

Remedy

All recalled vehicles will be fitted with a modified brake vacuum pipe along with a revised design non-return valve in the secondary port of the vacuum pump.

---

Recalls Number (Vehicles Effected)

R/2009/051 (14330)

Manufacturer Reference

P008

Defect

Fuel may leak from the fuel pump front bearing which could lead to poor performance smell of fuel fuel leakage at the rear of the engine fuel leak onto the ground and in the worse case fire.

Remedy

Recall the vehicles that are likely to be affected to replace the high pressure fuel pump drive belt belt tensioner the high pressure fuel lines and the fuel filter.

---

Recalls Number (Vehicles Effected)

R/2009/073 (77262)

Manufacturer Reference

P017

Defect

It has been identified that some vehicles may experience a reduction in braking performance leading to increased stopping distance due to the possibility of oil entering the brake booster or the brake vacuum pump non-return valve sticking in the closed position after cold start.

Remedy

All recalled vehicles will be fitted with a modified brake vacuum pipe along with a revised design non-return valve in the secondary port of the vacuum pump.

---

Recalls Number (Vehicles Effected)

R/2009/051 (14330)

Manufacturer Reference

P008

Defect

Fuel may leak from the fuel pump front bearing which could lead to poor performance smell of fuel fuel leakage at the rear of the engine fuel leak onto the ground and in the worse case fire.

Remedy

Recall the vehicles that are likely to be affected to replace the high pressure fuel pump drive belt belt tensioner the high pressure fuel lines and the fuel filter.

---

Recalls Number (Vehicles Effected)

R/2006/079 (6226)

Manufacturer Reference

Defect

It is possible for the wheel balance weights to foul the left front brake hose and/or the ABS wheel speed sensor and/or the brake pad wear warning sensor.

Remedy

Recall the vehicles that are likely to be affected to fit stick on wheel balance weights in place of the clamp on weights. A handbook supplement will also be produced stating the requirement for stick on weights.

---

Recalls Number (Vehicles Effected)

R/2005/156 (917)

Manufacturer Reference

A023

Defect

Due to the presence of an out of specification component within the automatic gearbox parking brake interlock system. The parking function may not fully engage when the operating lever is moved to park despite all indicators showing that park has been achieved. If the parking brake is not applied the vehicle may roll away.

Remedy

Recalled vehicles will have the out of specification component replaced with a quality assured item.

---

Recalls Number (Vehicles Effected)

R/2005/154 (277)

Manufacturer Reference

A021

Defect

Some vehicles may have been manufactured with a seat belt buckle mounting with a tensile strength below the required standard. If in the event of an accident where the rear left second row seat belt was being used the buckle may not be fully retained.

Remedy

Recall the affected vehicles inspect and replace seat belt buckle where required.
